The speed monitor DD0203 from ifm electronic supply the basic functions of the speed monitoring or standstill detection, by the pulse evaluation of an external sensor for example inductive sensor. All setting of the speed monitor DD0203 are made intuitive via four potentiometers. The unit features a semiconductor output and one relay output. Thanks to the wide-range power supply of the speed monitor DD0203 can be used at 24- 27 V DC or 110-240 V AC.
Specification
Features
Catalog
Youtube
Specifications
Details
Housing
Housing for DIN rail mounting
Ambient temperature
-25 °C to 60 °C
Protection
IP 20
Application
universal evaluation of pulse sequences with regard to overspeed and underspeed; Rotational speed monitoring
Short-circuit protection
yes
Weight
241g
Material Type
plastics: PC-GF20
For detecting frequency, speed and rotational speed
Reliable monitoring of overspeed or underspeed
Easy setting of the switch point via potentiometer
Clearly visible LEDs for displaying operation, function, switching status and release
